Basic Info.

Model NO.	XC-01
Color	Gary and Beige
Material	PP
Purification Rate	98%
Screw	Multi-Screw
Certification	Gma, QS, CE
Condition	New
Transport Package	Wood Carton
Specification	customized
Trademark	XC-01
Origin	China
HS Code	8421399090
Production Capacity	1set/15days

Product Description

1.Working Principle:
Packed tower scrubbers (also referred to as packed bed ,air stripping column/tower or packed column scrubbers) are designed for chemical scrubbing of contaminants from gas streams. Internal packing in the scrubber housing provides a large wetted surface area to induce intimate contact between the contaminated gas and the scrubbing liquid. The contaminant is then absorbed into or reacted with the scrubbing liquid. Recirculation of the scrubbing liquid, which may contain caustic or acid scrubbing agents, is often required to achieve the desired outlet emissions.

Wet packed scrubbers for the removal of corrosive, noxious and odourous gases from airstreams. Designed for high collection efficiency, maximum corrosion resistance. Scrubber design is characterized by low liquid irrigation rates, high volume air flow and low pressure drop.

2. The equipment features:1. The equipment is applicable to continuous and intermittent exhaust waste gas treatment.

2. It can purify various of pollutants at the same time, and has good defogging performance.

3. The packing adopts high efficiency and low resistance environmental protection ball, it can thoroughly remove the odors and harmful substances in the gas.

4.Material: The whole body of the tower adopts brand-new PP board, which has the advantages of anti-corrosion, anti-aging, anti-ultraviolet and so on. Suitable for a variety of work environments.

5.Configuration: The vertical anticorrosion pump in the spray tank inside the tower body can be idled, no dry burning, no leakage and easy to maintain. The auxiliary water tank is controlled by floating ball, automatic water feeding and no manual maintenance

3.Uses of Wet Packed Scrubbers1.Chemical Plants for noxios gas control2.Waste water treatment plants for odour control3.Rendering plants for odour control4.Tanneries for hydrogen sulphide control5.Pulp & Paper plants for noxious gas control6.Particle Board plants for formaldehyde control7.Food processing plants for odour control

8.Acid mist easily generated in the chemical industry9.Harmful organic waste gas purification

Gas purification rate

The name of gas	Molecular formula	The kind of cleaning mixture	Removal rate
Hydrochloric acid	HCl	H2O	90~95%
		NaOH	95~99%
Hydrofluoric acid	HF	H20	90~95%
		NaOH	95~99%
Annonia gas	NH3	H2O	90~95%
		H2SO4	>99%
Cyanic acid	HCN	NaOH	90~98%
Sulfur dioxide	SO2	NaOH	>95~99%
Chlorine	Cl2	NaOH	>95~99%
Hydrogen sulfide	H2S	NaOH	95~99%
Sulfuric acid	H2SO4	H2O	>95~99%
Chromic acid	CrO3	H2O	95~99%
Sodium hydroxide	NaOH	H2O	95~99%
Nitric acid	HNO3	H2O	90~99%

Sweet type

1. About product customization: We can customize the processing according to customer requirements.2. About engineering installation: We can arrange professional engineers to conduct on-the-spot investigations, give professionalsolutions, and arrange professional engineering teams to go to the site for installation and construction.3. About after-sales: Our equipment will have a one-year shelf life, we can provide repair and replacement.

Wet scrubber standardized production parameter list

Air volume	Washing tower size mm	height	thickness	Import and export size	Pump power	weight/kg	Wind resistance/pa
3000	800	4200	8	315	0.75KW	144	500
5000	1000	4200	8	400	1.1KW	240	500
8000	1200	4200	8	500	1.5KW	360	500
10000	1500	4700	8	600	2.2KW	600	500
15000	1800	5100	10	650	3KW	840	500
20000	2000	5100	10	700	4KW	1080	500
25000	2200	5200	10	750	5.5KW	1320	600
30000	2500	5200	12	800	5.5KW	1800	600
35000	2800	5500	12	900	7.5KW	2040	600
40000	3000	5500	12	1000	7.5KW	2640	600

FAQ:
1. Q. Are you a trading company or manufacture?

A: We are manufacture; we have our professional manufacturing teams and technicians

2. Q. How long is the warranty of your equipment?

A: One year warranty, in the meanwhile, quality inspection before delivery; during the warranty period, we

can replace the damaged consumables for free, after the warranty period, we have a good price for

consumables for our customers.

3. Q: Do you have technical support?

A: Our Company is responsible for installation and debugging of equipment, meanwhile, responsible for the

technology and operation training for user operator.

4. Q: Is overseas after-sales service available?

A: Yes, and after installation we will teach you basic operation and maintenance method.

5. Q: May I customize my own equipment?

A: Yes, please inform us your needs in details and we will design the facility per your data.
